Dvr 16 canale compresie H.264 960h DVR5116-HE

5
  • img-lg
  • img-lg
  • img-lg
  • img-lg

Cod Produs: DVR5116-HE

Compară cu alte produse

Comenzi telefonice: 0269-202.133

1518 85 Lei

în stoc

set-qtyADAUGĂ ÎN COȘ
  • trustLivrare 24h

    Livrarea se face la adresa specificată de client, de regulă în 24 de ore de la expedierea Comenzii şi poate ajunge la maxim 48 de ore pentru livrarea în zone rurale.

  • trustSuport tehnic

    Prin suportul tehnic oferit de catre firma noastra puteti instala /mentine sistemele dumneavoastra in perfecta stare de functionare

  • trustRetur bani 30 zile

    Garanţie retur extinsă pentru 30 de zile.

  • trustGaranție 2 ani

    Garantia produsului

  • Specificații tehnice
  • Caracteristici
  • Catalog
  • Review
  • 16 intrari video analogic+IP Megapixel,
  • 4 intrare audio,
  • Inregistrare cu 400 fps WD1, 960H(960x576),
  • Inregistrare la detectie miscare, dupa orar, continuu sau intrari alarma, LAN, webserver,
  • CMS (soft dispecerat) gratuit pentru 300 canale,
  • 2 porturi USB,
  • RS485 pentru comanda speed domuri,
  • Suporta 1 hard disk SATA II ,
  • 1 iesire videocomplex,
  • 1 iesire VGA,
  • 1 iesire HDMI,
  • Dual stream,
  • Permite vizualizarea direct de pe telefonul mobil 3G Smartphone (Android, iPhone, Win mobile, Symbian, BlackBerry),
  • Playback simultan pentru 16 canale,
  • Operare pentaplex,
  • Telecomanda,
  • Controlul meniurilor cu mouse USB,
  • Controlul speed domurilor cu mouse direct pe imagine (3D intelligent location - click on image),
  • Dimensiune mini 1U 325mm x 245mm x 45mm
Model DVR5104HE DVR5108HE DVR5116HE



System

Main Processor Embedded processor
Operating System Embedded LINUX



Video

Input 4 channel, BNC 8 channel, BNC 16 channel, BNC
Standard NTSC(525Line, 60f/s), PAL(625Line, 50f/s)



Audio

Input 4 channel, RCA
Output 1 channel, RCA
Two-way Talk Reuse audio input/output channel 1



Display

Interface 1 HDMI, 1 VGA, 1 TV, BNC(1.0Vp-p, 75Ω)
Resolution 1920×1080, 1280×1024, 1280×720, 1024×768, 800×600
Display Split 1/4 1/4/8/9 1/4/8/9/16
Privacy Masking 4 rectangular zones (each camera)
OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording



Recording

Video/Audio Compression H.264 / G.711
Resolution 960H/D1/4CIF(704×576/704×480) / CIF(352×288/352×240) / QCIF(176×144/176×120)
Record Rate Main Stream: 960H/D1(1~25/30fps)
Extra Stream QCIF(1-25/30fps)/CIF(1-6/7fps)
Bit Rate 48~3072Kb/s
Record Mode Manual, Schedule(Regular(Continuous), MD), Stop
Record Interval 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec



Video Detection& Alarm

Trigger Events Recording, PTZ, Tour, Video Push, Email, FTP, Spot, Buzzer & Screen tips
Video Detection Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
Alarm Input 4 channel 8 channel 16 channel
Relay Output 3 channel 1channel



Playback & Backup

Sync Playback 1/4 1/4/9 1/4/9/16
Search Mode Time/Date, MD & Exact search (accurate to second)
Playback Functions Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup Mode USB Device / Network



Network

Ethernet RJ-45 port (10/100M)
Network Functions HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter
Max. User Access 20 users
Smart Phone iPhone, iPad, Android, Windows Phone



Storage

Internal HDD 1 SATA port, up to 4TB



Auxiliary Interface

USB Interface 2 ports (1 Rear), USB2.0
RS485 PTZ control



General

Power Supply DC12V/2A
Power Consumption 10W(without HDD)
Working Environment -10 ~+55°C / 10~90%RH / 86~106kpa
Dimension(W×D×H) Mini 1U, 325mm×245mm×45mm
Weight 1.5KG(without HDD)
